RS-HSE6602 Parking Arm Gate Vehicle Flow Security Dustproof & Waterproof Parking Barrier

RS-HSE6602 Parking Arm Gate Vehicle Flow Security Dustproof & Waterproof Parking Barrier

Product Introduction

The RS-HSE6602 Parking Arm Gate is a high-performance access control solution engineered to optimize vehicle flow and enhance security for parking facilities worldwide. As a premium parking arm gate, it features a powerful DC servo brushless motor that enables ultra-fast opening and closing speeds of 0.3-1 seconds (adjustable based on barrier arm type), significantly reducing vehicle queuing time and improving operational efficiency. With a rated voltage of 24VDC, 480W input power, and 18A rated current, this parking arm gate delivers stable and reliable performance even in high-traffic scenarios.

Boasting an exceptional service life of over 10 million cycles and an MTBF of 10 million operations, it ensures long-term durability for demanding environments. Designed with an IP54 protection level, it is dustproof and water-resistant, making it suitable for use at elevations below 2000 meters in areas free of corrosive substances. Its compact dimensions (335*340*1050mm) and low standby power (within 2W) offer energy efficiency and easy installation. Whether deployed in commercial parking lots, residential complexes, toll gates, or industrial access points, this parking arm gate withstands extreme temperatures (-35℃ to 80℃) and harsh weather, providing seamless and secure vehicle access control.

Product Features

• Ultra-fast operation: 0.3-1s opening/closing speed (barrier arm-dependent) for efficient traffic flow management
• DC servo brushless motor: Ensures low noise, stable performance, and an extended service life of ＞10 million cycles
• Energy-efficient design: Standby power within 2W minimizes energy consumption during idle periods
• IP54 protection level: Dustproof and water-resistant, suitable for outdoor and semi-outdoor installations
• Wide temperature adaptability: Operates reliably in -35℃~80℃, adapting to extreme cold and hot climates
• High MTBF: 10 million operations for long-term reliability in high-traffic parking facilities
• Powerful performance: 24VDC rated voltage, 480W input power, and 18A rated current for consistent operation
• Compact dimensions: 335*340*1050mm size for easy installation in limited spaces
• Flexible motor compatibility: Supports DC24V motors with a maximum power of 500W for customized configurations

Product Specification Table

<<

Brief Description

• Product: RS-HSE6602 Parking Arm Gate
• Rated Voltage: 24VDC
• Running Speed: 0.3-1S (barrier arm-dependent)
• Input Power: 480W
• Service Life: ＞10 million times
• Protection Level: IP54
• Ambient Temperature: -35℃~80℃
• Dimensions: 335*340*1050mm
• Motor Type: DC servo brushless motor

Application Areas

This parking arm gate is designed for efficient vehicle access control in diverse scenarios, including:

• Commercial Parking Lots: Malls, office buildings, and shopping centers to manage high-volume vehicle entry/exit
• Residential Complexes: Gated communities and apartment buildings for secure vehicle access and visitor management
• Toll Gates & Highways: Expressways, bridges, and tunnels for fast toll collection and traffic flow control
• Industrial Areas: Factories, warehouses, and industrial parks to restrict vehicle access to authorized personnel
• Logistics & Distribution Centers: Ports, terminals, and logistics hubs to manage truck and vehicle movement
• Public Facilities: Airports, railway stations, and stadiums to handle peak-hour vehicle traffic
• Office Parks: Corporate campuses and business parks for organized employee and visitor parking
• Educational Institutions: Schools, colleges, and universities to secure campus vehicle entry and parking spaces
