RS218-4 Vertical Tripod Turnstile Doors Compact & Reliable Security Solution

The RS218-4 Vertical Tripod Turnstile Doors are a premium access control system crafted from high-grade 304 stainless steel, offering exceptional durability, corrosion resistance, and a compact design that fits seamlessly in various spaces. These Vertical Tripod Turnstile Doors feature three rotating arms that operate in one or two directions, effectively preventing unauthorized access to restricted areas while ensuring smooth passage for authorized users.

Controlled by access control systems, biometric identifications, push buttons, or card swiping, the electromagnet unlocks instantly upon receiving a valid signal, enabling quick entry with an open/close time of 0.3-0.6 seconds. With a lightweight net weight of about 35kg per unit and dimensions of 320x260x1050mm, these Vertical Tripod Turnstile Doors are easy to install and operate reliably, boasting noiseless and smooth performance.

Capable of handling 30-40 people per minute with a 550mm clear passage width, they efficiently manage pedestrian flow in high-traffic environments. Suitable for high-security places, factories, fitness clubs, prisons, hotel lobbies, schools, ports, and exhibition halls, these Vertical Tripod Turnstile Doors integrate seamlessly with all access control systems, delivering cost-effective security and crowd management for businesses and institutions of all sizes.

Key Features of Vertical Tripod Turnstile Doors

• Flexible operation: bidirectional or one-way rotation to meet different access needs
• Multiple control methods: authorized card, biometric identification, push button, or card swiping
• Seamless integration with all types of access control systems for enhanced security
• High-brightness LED lamp provides clear flow direction guidance for users
• Power-off auto-drop arm design allows free exit/entrance during emergencies
• Manual arm raising when powered on, ensuring energy-efficient operation
• Card reading memory function with adjustable single or multiple pass settings
• Built-in failure detection and alarm system for timely maintenance and security alerts
• Noiseless and smooth operation for a comfortable user experience
• Optional features including counter, voice speech, remote control, cooler fan, and thermostat

Vertical Tripod Turnstile Doors Specifications

Quick Specification Highlights

• Material: 304 stainless steel
• Size: 320x260x1050mm
• Net Weight: About 35kg/unit
• Transit Speed: 30-40 people/minute
• Clear Passage Width: 550mm
• Open/Close Time: 0.3-0.6S
• Input Voltage: AC110V/AC220V±10%
• Communication Interface: RS485
• Work Environment: Indoor & outdoor (shelter)

Applications of Vertical Tripod Turnstile Doors

The RS218-4 Vertical Tripod Turnstile Doors are widely applicable in scenarios requiring efficient access control and security management:

• High-security facilities and correctional institutions (prisons)
• Factories and industrial plants
• Fitness clubs and recreational centers
• Hotel lobbies and hospitality venues
• Schools, colleges, and educational institutions
• Ports, terminals, and transportation hubs
• Exhibition halls and event venues
• Office buildings and commercial complexes
• Government buildings and restricted access areas
