RS816 Turnstile Security Gate Round Design Glass Sides Good Compatibility with Different System

RS816 Turnstile Security Gate Round Design Glass Sides Good Compatibility with Different System

Product Introduction

The RS816 Turnstile Security Gate is a professional bi-directional access control device engineered to safeguard restricted areas while ensuring efficient pedestrian flow. As a premium turnstile security gate, it features a sleek cylinder design with 304 stainless steel construction, blending durability with aesthetic appeal for diverse environments. Operating in a normally closed mode, its tempered glass or acrylic barriers retract into the pedestal only after valid authentication—such as authorized cards, biometrics, or push buttons—effectively deterring unauthorized entry and tailgaters.

Equipped with a 24V servo motor, this turnstile security gate offers adjustable speed and rapid opening/closing times (0.2-2s), supporting a transit capacity of 40-45 people per minute for high-traffic scenarios. Ten pairs of sensor beams enable anti-punch and anti-tailgating protection, ensuring only one person passes per valid credential. It seamlessly integrates with all types of access control systems and works in both indoor and sheltered outdoor settings. Ideal for bank lobbies, office buildings, prisons, schools, and exhibition halls, this turnstile security gate delivers reliable, efficient security for both general and high-security environments.

Product Features

• Slim cylinder design (168x168x1000mm) with elegant appearance, saving space and complementing various decor styles
• Fast operating speed with adjustable opening/closing time (0.2-2s) for flexible traffic management
• Reliable lock and unlock system ensuring stable security performance in long-term use
• Bi-directional control supported by authorized cards, biometrics, push buttons, and other authentication methods
• Seamless integration with all kinds of access control systems for expanded functionality
• High-brightness RGB LED lights (blue/green/red/white) provide clear flow direction guidance
• Anti-punch function: barriers won’t close if people are detected inside the passageway
• Anti-tailgating design: only one person allowed to pass per valid authentication to prevent unauthorized entry
• Anti-panic feature: barriers open automatically during power outages for safe and rapid evacuation
• Dual operation modes: normally closed (standard security) or normally open (for group passage)
• Remote control support for convenient opening and closing operations
• Card reading memory function: user-configurable for single or multiple time card reading passing
• Failure detection and alarm functions for timely security alerts and maintenance
• Durable construction: 304 stainless steel body and plexiglass top cover resist corrosion and impact

Product Specification Table

Brief Description

• Model: RS816 turnstile security gate
• Material: 304 stainless steel (body) + plexiglass (top cover)
• Input Voltage: 220V AC ±10%
• Motor: 24V servo motor
• Transit Speed: 40-45 people/minute
• Close & Open Time: 0.2-2s
• Clear Passage Width: 600mm-900mm
• Sensor Beams: 10 pairs of sensors
• Service Life: 8,000,000 operations

Application Areas

This RS816 turnstile security gate is suitable for the following scenarios requiring strict access control and reliable security:

• High-security places (e.g., prisons, data centers, government buildings)
• Financial institutions (e.g., bank lobbies, vault entrances)
• Commercial buildings (e.g., office buildings, hotel lobbies, shopping malls)
• Industrial sites (e.g., factories, ports, warehouses)
• Recreational facilities (e.g., fitness clubs, exhibition halls, stadiums)
• Educational institutions (e.g., schools, colleges, research centers)
• Public infrastructure (e.g., subway stations, airports, railway stations)
